Description
THE NEW UPGRADED OVERLORD NOW HAS A LONGER TOP TUBE, SEALED INTEGRATED HEADSET, SEALED HUBS, MYTHOS PEDALS, SUMO GUARD SPROCKET & TWO PEGS MAKE THIS PACKAGE READY TO HIT THE STREETS.
Frame: Hand Welded Hi-Ten Steel, 20.75" TT
Fork: Tapered legs & one-piece steerer w/ Compressor topcap
Bars: Fiction 4-Stroke 9.00” 4-piece bars
Grips: Fiction Flanged 160mm
Barends: Fiction Troop
Stem: Fiction Spartan TL, 52mm
Headset: Standard 1 1/8″ Threadless
Brake Lever: APSE Alloy w/ Hinged Clamp
Brakes: APSE U25 Alloy U-brake
Cranks: Tubular Chromoly arms, 8 Spline Chromoly spindle, 165mm
Sprocket: Stolen Alloy 25T w/ SUMO Thermalite Guard
Bottom Bracket: Sealed MID 19mm, 8 spline
Pedals: Fiction Mythos w/ Chromoly spindles
Chain: Z-410, Black
Front Hub: Stolen Rampage Sealed 3/8″ axle
Rear Hub: Rampage 6061 Alloy Cassette w/ 14mm Chromoly Axle
Driver: 9t Sealed, One-Piece Chromoly
Front Rim: Fiction Trojan Alloy (Single-wall)
Rear Rim: Fiction Trojan Alloy (Single-wall)
Pegs: 2x 35x105mm Black
Seat: Stolen Fiction Moto Combo seat
Seat Post: 200mm included w/ seat
Seat Clamp: Integrated in frame
Front Tire: Fiction Atlas 2.30″
Rear Tire: Fiction Atlas 2.30″
Weight: Approx 25.5lbs (W/O Pegs)
Colors: Snow Blind White or Black Sabbath
Toptube Length: 20.75"
Chainstay Length: 13.75"
Headtube Angle: 74.5°
Seattube Angle: 71°
Standover Height: 8.75″
Bottom Bracket Height: 11.75"
Fork Offset: 32mm
DETAILED SPECIFICATIONS
Frame: Hand Welded Hi-Ten Steel, 20.75" TT
Fork: Tapered legs & one-piece steerer w/ Compressor topcap
Bars: Fiction 4-Stroke 9.00” 4-piece bars
Grips: Fiction Flanged 160mm
Barends: Fiction Troop
Stem: Fiction Spartan TL, 52mm
Headset: Standard 1 1/8″ Threadless
Brake Lever: APSE Alloy w/ Hinged Clamp
Brakes: APSE U25 Alloy U-brake
Cranks: Tubular Chromoly arms, 8 Spline Chromoly spindle, 165mm
Sprocket: Stolen Alloy 25T w/ SUMO Thermalite Guard
Bottom Bracket: Sealed MID 19mm, 8 spline
Pedals: Fiction Mythos w/ Chromoly spindles
Chain: Z-410, Black
Front Hub: Stolen Rampage Sealed 3/8″ axle
Rear Hub: Rampage 6061 Alloy Cassette w/ 14mm Chromoly Axle
Driver: 9t Sealed, One-Piece Chromoly
Front Rim: Fiction Trojan Alloy (Single-wall)
Rear Rim: Fiction Trojan Alloy (Single-wall)
Pegs: 2x 35x105mm Black
Seat: Stolen Fiction Moto Combo seat
Seat Post: 200mm included w/ seat
Seat Clamp: Integrated in frame
Front Tire: Fiction Atlas 2.30″
Rear Tire: Fiction Atlas 2.30″
Weight: Approx 25.5lbs (W/O Pegs)
Colors: Snow Blind White or Black Sabbath
GEOMETRY
Toptube Length: 20.75"
Chainstay Length: 13.75"
Headtube Angle: 74.5°
Seattube Angle: 71°
Standover Height: 8.75″
Bottom Bracket Height: 11.75"
Fork Offset: 32mm
