INSIGHT INTEGRATED HEADSET 1-1/8"

Product Overview

The Insight Integrated Headset is a sealed bearing headset designed for frames and forks with 1-1/8" integrated cups and 1-1/8" steerer tubes. Built with 45-degree sealed cartridge bearings and CNC-machined 6061 aluminum components, it delivers smooth steering and durability for racing and street riding. This is a drop-in replacement headset for modern BMX frames using the integrated standard.

Key Features

• 45/45 sealed cartridge bearings - Keeps dirt and water out while maintaining smooth rotation with minimal friction, reducing maintenance frequency
• CNC-machined 6061 aluminum construction - Lightweight and strong, with precision tolerances for proper fit and bearing alignment
• Integrated cup design - Works with frames that have built-in bearing races, eliminating the need for pressed cups and reducing stack height
• 41.8mm external diameter - Standard size for most modern integrated BMX headsets, ensuring wide compatibility across brands

Technical Specifications

• Headset Type: Integrated
• Steerer Tube Diameter: 1-1/8"
• Bearing Type: 45/45 sealed cartridge
• Material: 6061 aluminum alloy, CNC-machined
• External Diameter: 41.8mm
• Crown Race: Integrated design (frame and fork must have integrated cups)

Compatibility and Ideal Use Cases

This headset is compatible with any BMX frame and fork combination that uses 1-1/8" integrated cups and a 1-1/8" steerer tube. It fits most modern race and street frames built in the last 10+ years. Not compatible with threaded, semi-integrated, or non-integrated (external cup) headset standards. Ideal for riders looking for a reliable, low-maintenance headset for racing, park, or street use where sealed bearings protect against the elements and maintain performance over time.
