Devon Smillie Signature Bars

Product Overview

The Devon Smillie Signature Bars are a pro-model handlebar made from 100% heat-treated butted chromoly for Devon Smillie. Available in two rise options (9.5" and 9.75") with 28" width, these bars feature 10.5° backsweep and 3° upsweep for comfortable hand positioning. Offered in black and chrome finishes for street, park, and trail riding.

Key Features

• 100% heat-treated butted chromoly construction – Post-heat-treated chromoly steel with variable wall thickness (butting) provides maximum strength-to-weight ratio and durability for aggressive riding
• Devon Smillie signature geometry – Dimensions and angles developed by pro rider Devon Smillie for his street and park riding style
• Two rise options – 9.5" and 9.75" rise heights allow riders to choose based on height preference and riding style
• 28" width – Moderate width balances control and leverage without excessive width; can be trimmed for narrower preference
• 10.5° backsweep – Generous backward angle provides natural, comfortable wrist positioning and reduces strain during extended sessions
• 3° upsweep – Moderate upward angle complements backsweep for ergonomic hand placement
• Two finish options – Available in black (painted or powder-coated) and chrome-plated finishes

Technical Specifications

• Rider: Devon Smillie signature model
• Material: 100% heat-treated butted chromoly steel
• Rise options: 9.5" (241.3mm) or 9.75" (247.7mm)
• Width: 28" (711.2mm)
• Backsweep: 10.5°
• Upsweep: 3°
• Bar clamp diameter: Not specified (likely 22.2mm standard BMX—verify stem compatibility)
• Grip area diameter: 22.2mm (standard BMX)
• Finishes available: Black, chrome
• Weight: Not specified
• Recommended use: Street, park, trails, freestyle BMX

Compatibility and Ideal Use Cases

These bars fit BMX stems—the clamp diameter isn't specified but is likely standard or oversized (25.4mm or 31.8mm). Verify your stem's clamp diameter before ordering to ensure proper fit. The 22.2mm grip area is universal and fits all BMX grips. The 9.5" and 9.75" rise options suit taller riders (approximately 5'9" and above) or those who prefer very upright positioning for street and park riding. The minimal 0.25" difference between rise options allows fine-tuning based on personal preference—9.5" for slightly lower positioning, 9.75" for maximum height. The 28" width is narrower than many modern bars (29-30" is common)—benefits riders who prefer quicker steering response, tighter spaces in street riding, or those who find wide bars uncomfortable. The width can be cut down further using a pipe cutter or hacksaw with guide—always cut equally from both sides to maintain balance. The generous 10.5° backsweep and 3° upsweep create comfortable wrist angles that reduce fatigue and strain, particularly beneficial for riders doing long sessions or experiencing wrist discomfort with bars that have less sweep. Best suited for street, park, and trail riding where Devon Smillie's riding style (technical street, creative lines, smooth style) influences the geometry. The heat-treated butted chromoly construction provides durability for hard impacts while keeping weight reasonable through variable wall thickness. Chrome finish offers classic aesthetic and corrosion resistance but shows scratches; black finish hides wear better but may chip on impacts. Ideal for intermediate to advanced riders who appreciate pro-model geometry and want bars proven by a respected street/park rider.
