Elevn 22.2 Slt Standard 5.75" Cruiser Handlebars

Elevn 22.2 SLT Standard 5.75" Cruiser Handlebars

Product Overview

The Elevn 22.2 SLT Standard is a race-focused cruiser handlebar featuring traditional sweep geometry optimized for track control and rhythm sections. Built from 4130 heat-treated chromoly with 13 butted construction, it delivers the responsive stiffness and predictable handling needed for competitive racing on varied track surfaces.

Key Features

• Traditional Sweep Geometry — Increased 10° back and 2° up sweep angles provide a familiar, comfortable riding position that enhances control through rhythm sections and jump sequences
• 4130 Heat-Treated Chromoly — Premium material offers superior strength and impact resistance, engineered for rigorous race conditions
• 13 Butted Construction — Variable wall thickness minimizes weight while maintaining critical stiffness in high-stress zones
• Race-Proven Design — Geometry developed and tested by competitive cruiser racers for responsive handling and consistent control
• Cross Bar Support — 3/4" (19.05mm) cross bar reinforcement adds lateral stiffness for responsive pedaling and maneuverability through technical sections
• Bar Location Helper — Etched line in the Elevn "E" graphic aids quick repositioning after handlebar removal, maintaining setup consistency between sessions
• Multiple Graphics Options — Black finish with blue, red, white, or neon yellow graphics; white specification graphics on grip area for quick visual reference

Technical Specifications

• Material: 4130 Heat-Treated Chromoly
• Construction: 13 Butted with variable wall thickness
• Clamp Diameter: 22.2mm
• Height: 5.75" (146.05mm)
• Width: 28.5" (723.9mm)
• Sweep Angle: 10° back, 2° up
• Cross Bar Diameter: 3/4" (19.05mm)
• Weight: 719g (25.36 oz)
• Finish Options: Black with blue, red, white, or neon yellow graphics

Compatibility and Ideal Use Cases

Compatible with any 22.2mm clamp stem. Designed specifically for cruiser racing applications where track control, rhythm section consistency, and jump stability are priorities. The traditional sweep geometry suits riders preferring a more familiar bar feel and enhanced comfort during extended racing sessions. Ideal for competitive racers, intermediate to advanced riders, and those building dedicated race bikes focused on track performance. The bar location helper simplifies setup adjustments during training and race preparation.

• Material: 100% 4130 heat treated Cro-mo
• Butted: 13 (variable thickness)
• Features:
• Rise: 5.75’’ / 146.05 mm
• Width: 28.5’’ / 723.9 mm
• Sweep: 10° / Up Sweep: 2°
• Cross Bar: 3/4’’ / 19.05mm
• Weight: 25.36 Oz / 719g

Colors: Black with blue, red, white, and Neon Yellow graphics, with white specification graphics on bar grip area.

Bar Location Helper: In the Elevn “E” graphic located to the left of the Knurled area, there is a line to help you line your bars with your stem for ease to get back to your desired position after removal.
