Elevn Integrated Headset 1-1/8

Elevn Integrated Headset 1-1/8″

The Elevn integrated headset is a lightweight BMX racing headset designed for frames and forks with 1-1/8″ integrated head tubes and steerer tubes. Featuring high-rolling 45°/45° sealed bearings in CNC-machined 6061 aluminum cups, this headset delivers smooth steering and durability at just 72 grams. The integrated design eliminates external cups for a clean, low-profile appearance and reduced weight.

Key Features

• 45°/45° Sealed Bearings – Precision sealed bearings with 45-degree contact angles provide optimal load distribution for smooth steering and long bearing life; sealed design keeps dirt and moisture out for consistent performance
• CNC-Machined 6061 Aluminum – Precision machining creates tight tolerances and consistent quality; aluminum construction keeps weight minimal while maintaining structural integrity
• Integrated Design – Bearings press directly into the frame's head tube without external cups, reducing weight and creating a streamlined appearance
• 41.8mm External Diameter – Standard size for 1-1/8″ integrated head tubes ensures proper fit in compatible frames
• Lightweight (72g) – Minimal weight contributes to overall bike weight reduction for racing applications where every gram counts

Technical Specifications

• Headset Type: Integrated (internal bearing seats)
• Steerer Tube Size: 1-1/8″
• Bearing Spec: 45°/45° sealed
• Material: 6061 aluminum, CNC-machined
• External Diameter: 41.8mm
• Weight: 72g
• Compatibility: 1-1/8″ integrated frames and forks

Compatibility and Ideal Use Cases

This headset fits BMX frames with 1-1/8″ integrated head tubes and forks with 1-1/8″ steerer tubes. The frame must have integrated bearing seats machined into the head tube (not external cup designs). Best suited for BMX racers who prioritize low weight and smooth steering for competitive racing. The 45°/45° bearing design provides excellent performance for the precise steering inputs required on technical race tracks. The lightweight construction makes this headset ideal for weight-conscious riders building competitive race setups where minimal rotational mass in the front end improves handling response. Not compatible with frames requiring external cup headsets or tapered steerer tubes. Verify your frame and fork specifications before purchasing to ensure proper fitment.
