ELEVN Tapered Integrated Headset 1-1/8" to 1.5"

Product Overview

The ELEVN Tapered Integrated Headset is designed for BMX frames with tapered head tubes (1.5" lower, 1-1/8" upper). Constructed from CNC-machined 6061 aluminum with sealed bearings, this headset includes both 1.5" and 1-1/8" lower fork races, allowing use with either tapered forks or standard 1-1/8" forks converted to fit tapered head tubes. Includes a complete compression kit with top cap, star nut, and compression bolt.

Key Features

• Tapered integrated design – Fits frames with integrated tapered head tubes (1.5" bottom cup, 1-1/8" top cup) for clean aesthetics and reduced stack height
• CNC-machined 6061 aluminum construction – Lightweight alloy top cap and compression components provide durability at 93 grams total weight
• Ultra-smooth sealed bearings – Sealed cartridge bearings protect against dirt and moisture while providing low-friction steering
• Dual lower fork race options – Includes two 7075 aluminum fork races: one for 1.5" tapered steerer tubes and one conversion race for 1-1/8" steerer tubes
• Fork conversion capability – The 1-1/8" conversion race allows standard non-tapered forks to work with tapered frame head tubes when used with the included 1.5" lower bearing
• Complete compression kit – Includes fully CNC'd alloy top cap, star nut, and compression bolt for ready-to-install setup

Technical Specifications

• Headset type: Tapered integrated (IS42/28.6 top, IS52/40 bottom)
• Head tube compatibility: 1-1/8" upper, 1.5" lower (tapered)
• Steerer tube compatibility: 1-1/8" to 1.5" tapered, or 1-1/8" straight (with conversion race)
• Material: 6061 aluminum (top cap, compression components), 7075 aluminum (fork races)
• Bearings: Sealed cartridge bearings (1-1/8" upper, 1.5" lower)
• Weight: 93 grams
• Included components:
  • 1 × 1-1/8" upper bearing
  • 1 × 1.5" lower bearing
  • 1 × CNC aluminum top cap
  • 1 × star nut
  • 1 × compression bolt
  • 2 × 7075 aluminum lower fork races (1.5" tapered and 1-1/8" conversion)

Compatibility and Ideal Use Cases

This headset fits BMX frames with tapered integrated head tubes only—specifically frames designed for 1-1/8" upper and 1.5" lower cups. It will NOT fit frames with standard 1-1/8" straight head tubes or external cup headsets. Compatible with either tapered forks (1-1/8" upper, 1.5" lower steerer tube) using the 1.5" fork race, or standard 1-1/8" straight steerer forks using the included conversion race. Important limitation: The 1-1/8" conversion race will not work on forks with integrated (built-in) lower bearing races on the steerer tube—it requires a fork with a separate press-on race design. Ideal for modern BMX race frames and high-end freestyle frames that use tapered head tubes for increased front-end stiffness. The conversion race option is useful for riders who want to run standard 1-1/8" forks in tapered frames. Verify your frame's head tube and fork steerer tube specifications before ordering.
