Excess Exe Carbon Rim 406x32mm 36h No Brake Surface

Excess EXE Carbon Rim 406x32mm 36h No Brake Surface

Product Overview

The Excess EXE is a lightweight 20" BMX carbon rim engineered with 3K weave construction and brakeless surface profile. Featuring low-profile aero geometry, presta valve compatibility, and tubeless-ready bead lock system, it delivers premium performance for brakeless and disc brake setups with minimal rotating weight.

Key Features

• 3K Carbon Weave Construction — Three-directional carbon fiber layup balances strength, stiffness, and lightweight performance without excess material in non-critical zones
• Low-Profile Aero Geometry — Reduced rim height minimizes aerodynamic drag while maintaining structural integrity and spoke bed durability
• Brakeless Surface Profile — Smooth, continuous braking surface eliminates mechanical brake pads, reducing rolling resistance and maintaining clean aesthetics for brakeless setups
• Tubeless-Ready Bead Lock System — Integrated bead lock geometry accepts tubeless conversion with compatible valve, tape, and sealant components, enabling weight reduction and puncture self-sealing capability
• Disc Brake Compatible — Designed for use as front or rear rim when paired with disc brake systems, providing braking flexibility across frame types
• High-Gloss Finish — Water-transfer graphics with clear coat provide premium aesthetics while protecting carbon structure from UV degradation and weathering
• Presta Valve Hole — Compatible with presta valves for tubeless and high-pressure applications
• Angled Nipple Holes — Precision nipple hole geometry optimizes spoke tension distribution and rim durability under high-tension spoke loads

Technical Specifications

• Material: 3K carbon fiber weave
• Wheel Size: 20" (406mm ETRTO)
• Rim Diameter (ERD): 377.4mm
• Rim Width: 32mm external, 25mm internal
• Rim Height: 25mm (low-profile aero)
• Spoke Holes: 36-hole (angled nipple holes)
• Valve Type: Presta
• Braking Profile: Brakeless surface (no mechanical brake pad surface)
• Brake Compatibility: Front or rear with disc brake systems
• Weight: 312g
• Recommended Spoke Tension: <115kgf
• Finish: High-gloss clear coat with water-transfer graphics
• Tubeless System: Bead lock compatible; requires additional tubeless valve, rim tape, and sealant for conversion

Compatibility and Ideal Use Cases

Compatible with 36-hole hubs, presta valves, and standard BMX spoke nipples. Designed for brakeless setups or disc brake systems using compatible caliper mounts. Tubeless conversion requires additional tubeless-specific valve, sealant rim tape, and liquid sealer (sold separately). Ideal for weight-conscious riders seeking premium carbon construction and minimal rotating mass. Suited for brakeless riding enthusiasts, disc brake racers, and those prioritizing aerodynamic efficiency. Recommended for riders seeking lightweight performance wheels with optional tubeless conversion capability for puncture self-sealing and further weight reduction.

EXCESS XLS 406x32MM RIM SPECIFICATIONS
ERD: 20": 377.4mm
Height: 25mm
Internal Rim Width: 25mm
External Rim Width: 32mm
Spoke tension recommended <115KGF

Tubeless Ready System - Our rims feature a Bead Lock System, needed for the rim to be Tubeless Ready. With the installation of additional items needed you can get the rim ready for tubeless set up, along with the usage of a tubeless specific tire. With a tubeless set up, you can lighten up your wheels, saveing rotational weight, as well as have a sealant inside your tubeless ready tire to help automatically repair small punctures.
Additional items needed to convert to a Tubeless system include Special Valve, Sealant Rim Tape, and Liquid sealer.

Disc Braking Compatible - Designed to be used as a front rim or a rear rim when using a disc brake.
