PRIDE RACING

Pride Racing Matrix Tapered Carbon Bmx Fork-24"x1 1/8-1.5"-orange/Gun Metal

$449.95
Shipping calculated at checkout.
Size
{}

Description

The Pride Racing Matrix Tapered Carbon BMX Fork-24"x1 1/8-1.5"-Orange/Gun Metal features a sophisticated two-part construction, meticulously crafted to optimize strength, stiffness, and impact resistance:

•Advanced Carbon Fiber Legs: The fork legs are constructed from 100% HM Toray® carbon, renowned for its exceptional strength-to-weight ratio. This premium carbon fiber is synergistically combined with an internal Polymer Matrix Interface (PMI) structure. This innovative integration significantly enhances overall stiffness and structural integrity, ensuring precise handling and efficient power transfer. Different types of Toray carbon fibers are strategically utilized, each selected for its specific properties to optimally manage lateral loads, torsional forces, and impacts encountered during aggressive BMX racing.

•High-Strength Aluminum Steerer: The steerer tube is precision-machined from 7075-T6 Aluminum, a high-strength aerospace-grade alloy. This choice guarantees outstanding structural integrity and long-term durability, providing a reliable connection between your handlebars and front wheel.

Engineered for Excellence

Designed with the competitive BMX racer in mind, the Pride Matrix fork meets the stringent EN 16054 standard, ensuring top-tier safety and performance compliance.

Key Features & Specifications

Feature
Specification
Material
Toray Carbon / 7075-T6 Aluminum
Wheel Size
20"
Axle Compatibility
20mm (Axle not included)
Steerer Diameter
Tapered 1"-1/8 - 1.5"
Steerer Length
165mm
Fork Height
309mm
Offset
30mm
Dropout Thickness
8mm
Compression Bolt
M22x1.5mm
Compression Bolt Length
20mm
Weight
659g (with compression bolt)

Critical Installation & Maintenance Guidelines

IMPORTANT: Always use a torque wrench for installation and maintenance. Adhering to these torque settings is crucial for safety and product longevity.
Component
Torque Setting (Max)
Compression Bolt
8 Nm
Stem Bolts
13 Nm
Hub Axle
8 Nm
IMPORTANT NOTES:

•BMX RACE ONLY: This fork is exclusively designed for BMX RACE applications. It complies with both EN and CPSC safety requirements for its intended use.

•Rider Responsibility: As a high-performance 100% Carbon fork, it is the buyer's responsibility to understand their own riding limits and the proper maintenance procedures for such advanced equipment. Carbon fiber is incredibly strong but cannot absorb major crash impacts without potential damage. Following any fall or collision, thoroughly inspect your fork. If any damage is suspected, it is YOUR responsibility to have it professionally inspected by a qualified technician.

•Torque Settings: Always respect the specified torque settings. For optimal performance and safety, we recommend using a split bearing ring if possible during installation.
Invest in the Pride Matrix Carbon BMX Race Fork and experience the pinnacle of racing technology.
Product Data
UPC/EAN:
